PACKAGE INCLUDES:
Adjustable Quick Detach Throw Lever Mount, Coupling Light Shroud,
Video Output Cable, Remote Control Pad, Batteries, Operators Manual,
Graphic Training Aid, Lens Cleaning Kit, Soft Carrying Case
An uncooled weapon sight that doubles as a portable reconnaissance
scope, the ThermoSight T70 and T75 are designed to interface with
scopes such as the ELCAN SpecterDR, Trijicon ACOG for the M-4, M-16,
and similar weapons.
The ThermoSight T75 Advanced Combat Thermal Sight utilizes a
Long-Wave Thermal Imaging sensor and
is a High-Resolution Clip-On Night Vision Device (CNVD) that mounts on
any Picatinny (MIL-STD-1913) rail interface forward of an existing
scope, adding night vision capabilities to daytime target acquisition
platforms.
The ACTS-LR has been specifically designed and optimized
for long range weapon platforms with an approximate 875
yard identification range. The size and weight make it
ideal for tactical small arms such as the FN
SCAR-MK16/17, M4/M16, SR25 all the way up to M107 .50
BMG and similar platforms.
The ACTS-LR converts the operation of day scopes to
thermal imaging, extending the useful period of
operation from daylight into nighttime. By mounting the
ACTS-LR directly in front of the day scope, the operator
can view the same scene with the ability to sense
infrared energy (heat) in all lighting conditions. It
is optimized for use with day scopes up to 12X. The
ACTS-LR can also be used as a stand alone weapon sight
and handheld thermal viewer.
The ACTS-LR is powered by (two or three AA batteries) or
(one or two CR123 batteries) installed in any
orientation. Using 3 AA Lithium Batteries, you can
expect approximately 6 hours of operating time and about
4 hours of operation (at 20°C/68°F) with two CR123
batteries. The batteries can be removed and replaced in
the field without removing the ACTS-SR from the weapon
system.
These
FLIR T75 Thermal Sights are proudly manufactured in the USA
The FLIR T75 was developed for SOCOM for use with long
range magnified optics. It is optimized to provide the
best image when paired with an 8X Magnified Scope, but can be
used with scopes up to 12-14x without much loss of
clarity due to its native 640×512 sensor. This
high resolution sensor and 17 micron detector provides incredibly
sharp detail and
shading for rich images and easier target
identification.
The FLIR T75 features the standard white hot/black hot
polarity modes. But, it also has the ability to show
images in full color using several palette options.
Gray (Grayscale) Palette provides
maximum contrast on targets against a uniform background
using black and white shades.
Iron Palette provides a color scale
that goes from dark red through yellow to white to
represent increasing temperatures.
Rain (Rainbow) Palette uses all the
colors of the rainbow from red through green, blue, and
yellow to violet to represent increasing temperatures.
Ice (Fire & Ice) Palette displays blue
for cold targets and red for hot targets.
Another useful feature of the T75 is the remote cable
control. This allows the operator to set up the
joystick controls elsewhere on the weapon for easier
access without breaking the firing grip/position. If
you are looking for the ultimate thermal clip-on sight
for long range optics, look no further.
The FLIR T75 Advanced Combat Thermal Sight – Long
Range (ACTS-LR) is an uncooled Thermal Clip-On Weaponsight with a low,
in-line profile suitable for modern weaponry with flip-down or
removable front sight posts. The low profile compliments current
Rifle Combat Optics (RCO’s)
and minimizes height above the rail. The ACTS-LR
provides scene clarity and allows the use of false color
to enable rapid target acquisition and firing solutions
using a high density, color Organic Light Emitting
Display (OLED).
The unit is installed, operated, and removed without tools and without
affecting boresight (permanent boresight alignment). The unit can be
mounted on a spotting scope for long range reconnaissance, hand-held
as a Night Observation Device (NOD), or used in other night-time
operations requiring Night Vision capabilities.
Optimized for close combat
assault rifles, including:
M4
M16
HK416
AK47
AR15
SCAR-16/17
SR25
FEATURES
Long-wave thermal
imaging sensor - Provides crisp
imagery in daylight and in total darkness, fog, smoke, dust, and most
obscurants
Compatible with Standard
Day Sights -
Compatible with all combat
optics and rapidly adaptable to most weapons platforms. Accurate in direct
view and clip-on modes.
In-Line design -
Low profile minimizes height above rail,
reducing interference with other devices and snag hazards.
Multi-use -
Optimized as a direct view thermal sight.
Can be used in front of a day optics as a clip-on, rail mounted thermal weapon
sight.
Ergonomic
user-interfaces -
Allows operators to
keep positive control of the weapon’s aiming point while
adjusting the sight.
Easy to use quick
detach locking throw lever -
Easy to use quick
detach locking throw lever. Compatible with any
MIL-SRD-1913 Picatinny rail system.
Dual control modes
- A
mini-joystick placed at the operator’s thumb when
supporting the weapon under the hand-guard or at a user
selected location via a wired remote control pad allows
operators to control the sight and adjust the IR image
without changing their hand positions.
Adjustable
field-of-view
No special
batteries required -
Accepts multiple
battery types. AA or CR123 (installed in any
orientation).
Bellows eye cup -
Keeps the operator
covert by
eliminating back illumination of the operator from the
viewfinder.
Rugged, Small and lightweight
Simple operation -
Visible options (Red) or near IR options
(for use with Night Vision Devices).
It’s all FLIR inside
- FLIR controls the entire supply
chain of the critical technology inside the T75, ensuring fast service and
long term support
Optimized as a direct view thermal sight, the
FLIR T75 ThermoSight Rifle Scope w/ 640x512 VOx Microbolometer Sensor Array
60601 can be used as a clip on, rail mounted scope that will be great
for all of your thermal needs. This Heat Seeking Riflescope from the experts
at FLIR is made with a wide field of view for increased situational awareness
and narrow field for identification and targeting. The mini joystick on the
FLIR ThermoSight T75 Thermal Weapon Scope
allows operators to control the sight and adjust the IR image without changing
their hand positions. Compatible with standard optics, the
FLIR Systems T75 ThermoSight Heat Seeking
Thermal Gun Sight will work with any MIL-SRD-1913 Picatinny rail
system. For a great way to make sure that you are working with one of the best
thermal scopes available, choose the FLIR T75
640x512 ThermoSight Riflescope.
BENEFITS
Designed to mount on any
MIL-STD-1913 rail interface forward of an existing scope, adding
blended thermal night vision capabilities to daytime target
acquisition platforms
Clip-on to
day-sight/RCO or use as stand-alone thermal sight for mission flexibility;
works with all combat optics and rapidly adaptable to various weapon platforms
Provides
crisp imagery through total darkness, fog, smoke, dust, and many other
obscurants
Precise target
acquisition using mini-joystick placed at operator’s thumb and/or remotely via
a control pad allowing operators to adjust and control the sight while keeping
hands on rails, grips, triggers, ammo-belts, etc.
Offers mission flexibility as a
high-resolution Night Vision Weaponsight, mounted on a tripod
for long range reconnaissance, handheld as an observation device, or
used in other nighttime operations requiring Night Vision capabilities
Effective on all weapons from
carbines to .50 caliber bolt action rifles, including the M4, M16,
HK416, and the AK47
Low
profile minimizes height above rail allowing installation of other devices (RCO's)
and minimizes snag hazards
Allows operators to keep positive control of the weapon’s muzzle while
adjusting the sight
Includes FLIR’s proprietary Shock
Mitigation System™ (SMS™), allowing the unit to be used on weapons up
to and including .50 caliber bolt-action rifles
Highly portable &
lightweight design (28 oz w/Batteries & Mount) reduces
operator fatigue
Large, rugged controls for basic
image adjustment, no complicated menus to navigate
LR: Ultra-wide for
increased situational awareness and narrow for enhanced
target identification
9.4° x 7.5° FOV
compliments standard RCO's. Three zoom capabilities, 1X,
2X, and 4X, for long range ID and engagement
Minimizes impact on
host weapon with its low profile
Designed for
extreme operating environments and tested to withstand
thousands of rounds of rapid fire gun shock
and reduces operator fatigue.
Hot swap standard
CR123 batteries, no downtime, never have to turn the
unit off, can be swapped while weapon mounted
Ensures covert
operation by eliminating illumination of the operator
from the viewfinder
FLIR controls the entire supply
chain on critical technology inside the T75 ACTS-LR
ensuring fast service and long term support
FLIR T-75
Advanced Combat Thermal Sight
